Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine

China SUZHOU LABELONG PACKAGING MACHINERY CO.,LTD certification
China SUZHOU LABELONG PACKAGING MACHINERY CO.,LTD certification
I'm Online Chat Now

Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine

Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine
Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine

Large Image :  Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine

Product Details:

Place of Origin: China
Brand Name: Labelong
Certification: CE
Model Number: RFC-C 24-24-8

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: $26,000.00
Packaging Details: Wooden case
Delivery Time: 20-40 days
Payment Terms: T/T OR L/C
Supply Ability: 50 Unit/Units per Year
Detailed Product Description
Product Name: 3kw Beer Bottle Filling Machine Automatic Grade: Automatic
Power: 3kw Dimension(L*W*H): 3100x2100 X2650
Weight: 4200 Kg Material: Stainless Steel
Usage: Beverage Packaging Capacity: 10000BPH
Highlight:

10000BPH Beer Bottle Filling Machine

,

3kw beer filling equipment

,

3kw Beer Bottle Filling Machine

Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine



1. The rinsing machine using high-strength stainless steel bottles of spring-loaded folders, to ensure a stable reversal of the glass bottles. The nozzle is a plum-like structure can wash every corner of the sidewall and bottom to make the bottle clean.



2. Filling machine with spring-type mechanical lifting equipment to upgrade glass bottles, large bearing support floundering in the vat and use of guide-rod in the orientation of the structure, there are pre-cover features.



3. Using high-precision mechanical filling valve, with cylinder liquid level and the back pressure controlled by a variable signal proportional. Fast, stable, accurate, to be vacuum one at a time.



4. Stainless steel plunger and mechanical stirring gland-type magnetic reasonable cap to ensure that the gland is healthy and reliable. Hopper and the cap.



Model RFC-C series 14-12-5 16-16-5 24-24-8 32-32-10 40-40-10 50-50-12
Washing-Filling-Capping 14-12-5 16-16-5 24-24-8 32-32-10 40-40-10 50-50-12
Producing capacity
(600ml)
2000-4000
(bph)
5000-7000
(bph)
8000-12000
(bph)
12000-15000
(bph)
16000-20000
(bph)
20000-24000
(bph)
Applicable bottle (mm) φ=50-108 H=170-340 330ml-2.25L
Pressure (kg/cm2) 2~3

Outside vacuum

pump power (kw)


Main motor
1.5kw
Main motor
2.2kw
Main motor
3kw
Main motor
4kw
Main motor
7.5kw
Main motor
9.5kw
Overall dimension (mm)

(LxWxH)
2100x1400
x2500
2460x1720
x2650
3100x2100
x2650
3500x2500
x2650
4600x1800
x2650
5200x4500
x3400
Weight(kg) 2500 3500 4200 5500 6800 7600




Shipping photo

Stainless Steel 10000BPH 3kw Beer Bottle Filling Machine 0

The company has advanced international equipment and technology, the machine mainly components and circuit electric appliance all come

from Italy, Switzerland, Germany, Taiwan and France. our Company's products with high performance, high technology content products.

The products sell well all over the world, in part of models are exported to southeast Asia, the Middle East, Europe and the United States,

Malaysia and other countries and regions in the world...
Professional makes best quality, Labelong together with you to create success.



FAQ

Q1: Are you a trading company or a manufacturer?

 A:  We are a manufacturer, we supply the factory price with good quality, welcome to visit.

Q2: What's your guarantee or the warranty of the quality if we buy your machines?
A:  We offer you the high quality machines with one year guarantee and supply long life technical  support.

Q3: When can I get my machines after I paid?
A:  The delivery time is based on the exact machine you confirmed.

Q4: How can I install my machines when they arrive?
A:  We will send our engineers to your factory to install the machines and train your staffs how to operate
the machines.

Q5: How about the spare parts?
A:  After we deal with all the things, we will offer you a spare parts list for you refer.
