PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L

China SUZHOU LABELONG PACKAGING MACHINERY CO.,LTD certification
China SUZHOU LABELONG PACKAGING MACHINERY CO.,LTD certification
I'm Online Chat Now

PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L

PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L
PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L

Large Image :  PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L

Product Details:

Place of Origin: China
Brand Name: Labelong
Certification: CE
Model Number: RGF-300

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: USD20000-50000/SET
Packaging Details: Wooden case
Delivery Time: 20-40 days
Payment Terms: T/T OR L/C
Supply Ability: 50-100SET/YEAR
Detailed Product Description
Product Name: 5 Gallon Filling Machine Filling Liquid: Mineral Water
Capacity: 300BPH Dimension(L*W*H): 2600*2300*2200MM
Function: Bottle Washing Filling Capping Automatic Grade: Automatic
After-sales Service Provided: Engineers Available To Service Machinery Overseas Packaging Material: Plastic
Packaging Type: Barrel,Bottles Material: Stainless Steel SUS304
Filling Material: Water Bottle Type: PET Plastic Bottle,5 Gallon Bottle
Highlight:

300bph Washing Filling Capping Machine

,

20L Washing Filling Capping Machine

,

Mineral Water 5 Gallon Filling Machine

300bph Automatic 5 Gallon 18.9L 19L 20L PET Bucket Bottle Mineral Water Washing Filling Capping Machine



300bph automatic 5 Gallon 20L PET barrel bottle drinking water Washing Filling capping Machine



Our QGF complete 5 gallon barrel pure,mineral water filler line mainly consists of 7 parts. They are respectively:
1. De-capping machine
2. External barrel brushing machine
3. Bottle feeding machine
4. Washing, filling, capping machine
5. Cap elevator
6. Lamp checker
7. Conveyor



Introduction:
This filling line specially for 3-5gallons barreled drink water, with type QGF-100, QGF-240, QGF-300, QGF-450, QGF-600, QGF-900, QGF-1200, It intergrates bottle washing, filling and capping into one unit, In order to achieve the purpose of washing and sterilizing, The washing machine use multi-washing liquid spray and-thimerosal spray, This thimerosal can be used circularly, The capping machine can cap barrel automatically , this line equips with water spraying device in order to ensure those caps sterilizer and clean. it also can automatically carry out barrel, washing, sterilizing, filling, capping, counting and products discharging, with complete function, modern design and high degree of automation, it is a new kind of barreeled water auto-production line, which intergrates mechanism, electricity and pneumatics technologies together .



5 Gallon Filling Machine Parameter
Model WFC-100 WFC-200 WFC-300 WFC-450 WFC-600 WFC-900 WFC-1200
Rated Production
Capacity (bph)
100 200 300 450 600 900 1200
Installed Capacity 1.3 1.7 3.8 3.8 7.5 9.7 13.5
Related Voltage(V) 380V/HZ 380V/HZ 380V/HZ 380V/HZ 380V/HZ 380V/HZ 380V/HZ
Weight (kg) 680 800 1500 2100 3000 3500 4500

PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 0
PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 1



PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 2PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 3

PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 4



Configuration List:
PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 5



Our factory


PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 6



PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 7PET Bucket Bottle Mineral Water Washing Filling Capping Machine 300bph 5 Gallon 20L 8
