Product Details:
Payment & Shipping Terms:
|
Material: | Stainless Steel 304 | Capacity: | CUSTOMIZED |
---|---|---|---|
Application: | Drinking Water,Cosmetics Industry,Chemical Industries,Food | Voltage: | 110V/220V/380V |
Control: | Automatic Control | Function: | Enlong The Life |
Control Method: | PLC/PLC+/touch Screen/DCS | Other Name: | Nitrogen Doser |
Air Supply: | Gas | ||
Highlight: | Liquid Nitrogen Injector Dosing Machine,SS304 Liquid Nitrogen Injector,PLC Liquid Nitrogen Injector Machine |
Apply for
Model | Speed | Nitrogen head | Arm length | Controller weight | Machine weight |
Doser-200 | 300bph | 51*248 | 740mm | 10kg | 17kg |
Doser-300 | 600bph | 51*248 | 740mm | 10kg | 17kg |
Specifications
Rated input voltage: 110VAC-60Hz / 220VAC-50H z + / -10%
Current: <=5A
Power supply: 220V / 50 HZ
Humidity: Relative humidity-0% -100%
Working altitude: can work at 3050 meters (10000FT)
Noise: Continuous noise <=78dB (A)
Overall weight: 32 KG
Filling speed 0-300, tank / per minute
Liquid nitrogen supply: adjust to 0.4-0.8Mpa to connect with the liquid nitrogen port.
Compressed air or nitrogen: used to supply the filling valve
