Product Details:
Payment & Shipping Terms:
|
| Product Name: | 3000 BPH Automatic Juice Filling Machine | Filling Liquid: | Juice |
|---|---|---|---|
| Capacity: | 3000BPH | Material: | 304 Stainless Steel |
| Weight: | 300kg | Control: | PLC |
| Bottle Type: | PET/ Glass Bottle | Power: | 3.29kw |
| High Light: | 3000 BPH Automatic Juice Filling Machine,3000 BPH juice pouch filling machine,3.29kw Automatic Juice Filling Machine |
||
3.29kw PET 3000 BPH Automatic Juice Filling Machine
RFC-H series filling machines are designed especially for bottling synthetic juices (RTS) or HOT filled juices, tea (filled at up to 98 centigrade degrees), with optional capacity ranging from 1000BPH to 32000BPH, it adopts the pressure & rotative filling style.
Automatic Juice Filling Machine integrates washing, filling and capping into one unit. It can be used for purified and mineral water filling. Also can used for hot beverages, such as fruit juice, tea drink, etc. The machine also can be used for carbonated drinks.
Automatic Juice Filling Machine Technical Parameter
| Model RFC-H series | 14-12-5 | 16-16-5 | 24-24-8 | 32-32-10 | 40-40-10 | 50-50-12 |
| Washing-Filling-Capping | 14-12-5 | 16-16-5 | 24-24-8 | 32-32-10 | 40-40-10 | 50-50-12 |
| Producing capacity (600ml) |
2000-4000 (bph) |
5000-7000 (bph) |
8000-12000 (bph) |
12000-15000 (bph) |
16000-20000 (bph) |
20000-24000 (bph) |
| Applicable bottle (mm) | φ=50-108 H=170-340 330ml-2.25L | |||||
| Pressure (kg/cm2) | 2-3 | |||||
| Outside vacuum pump power (kw) |
Main motor 1.5kw |
Main motor 2.2kw |
Main motor 3kw |
Main motor 4kw |
Main motor 7.5kw |
Main motor 9.5kw |
| Overall dimension (mm) (LxWxH) |
2100x1400 x2500 |
2460x1720 x2650 |
3100x2100 x2650 |
3500x2500 x2650 |
4600x1800 x2650 |
5200x4500 x3400 |
| Weight(kg) | 2500 | 3500 | 4200 | 5500 | 6800 | 7600 |
Application: beverage juice
Capacity: 1000-32000 bottles / hour (500ML)
Containers applied for: PET bottle of all volumes and shapes
Filling system: hot filling
Configuration List
Our factory
Shipping photo
RFQ
Q1: Are you a trading company or a manufacturer?
A: We are a manufacturer, we supply the factory price with good quality, welcome to visit.
Q2: What's your guarantee or the warranty of the quality if we buy your machines?
A: We offer you the high quality machines with one year guarantee and supply long life technical support.
Q3: When can I get my machines after I paid?
A: The delivery time is based on the exact machine you confirmed.
Q4: How can I install my machines when they arrive?
A: We will send our engineers to your factory to install the machines and train your staffs how to operate
the machines.
Q5: How about the spare parts?
A: After we deal with all the things, we will offer you a spare parts list for you refer.
