Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle

Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle
Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle

Large Image :  Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle

Product Details:

Place of Origin: China
Brand Name: Labelong
Certification: CE
Model Number: L-12H

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: USD5000-20000/SET
Packaging Details: Wooden case
Delivery Time: 20-40 days
Payment Terms: T/T OR L/C
Supply Ability: 50-100SET/YEAR
Detailed Product Description
Product Name: Linear Bottle Filling Machine Filling Liquid: Cooking/edible Oil
Capacity: 500-3000BPH Material: SUS304
Brand: Labelong Control: PLC
Bottle Type: Pet/glass Bottle Function: Filling Capping
Automatic Grade: Automatic Driven Type: Electric
Condition: New Type: Filling Machine
Voltage: 220V/380V
High Light:

SS Bottle Filling Capping Machine

,

Automatic Glass Bottle Filling Capping Machine

,

PLC Oil Linear Bottle Filling Machine



Automatic stainless steel Cooking/olive Edible Oil PET/Glass bottle Filling Capping machine





It adopts electric dynamic components of world famous brands, with PLC control,friendly operation interface, long service life of parts, convenient maintenance, safe and reliable, low noise, simple operation and accurate measurement and adjustment.



Application: detergent, oil, toilet cleaner, soap water, sauce, jam, honey


Capacity: 500-5000 bottles / hour (500ML)


Containers applied for: PET /glaa bottle of all volumes and shapes


Filling system: piston filling.



  1. Control system – with PLC control system, filling dose is of random fine-tuning.
  2. Operation Interface – 6-inch color touch-style user interface, intuitive and simple, safe and reliable, servo motor driving.
  3. Feature Enhancements – Cutting with anti-drip device, it can dive to fill with functional properties of materials. (This feature can be optional)
  4. Electrical components – using internationally renowned brands to ensure that equipment’s reliability and high accuracy;
  5. Mechanical components – the filling valves are made of high quality stainless steel 304 and non-toxic corrosion and PTFE or silica gel hoses. Whole machine are made of high quality stainless steel 304.
  6. Count testing – real-time count, reflecting on the work output directly.
  7. Filling Detection – No bottle, or when bottles are not enough, no filling.
  8. Maintenance situations – the machine meets the GMP requirements, easy to disassemble, clean and maintain.
  9. Exchange standard – when changing filling specifications, you only need some simple adjusting to make it.


Technical Parameters:



Machine dimension 2000mm(L)* 1200mm(W)*2500mm(H)
Filling heads Accorting to production capacity
Filling range Customized
Production capacity: 1000b/h(take 500ml foamy product as test) for 6 filling heads
Filling Tolerance Filling machine for volume ≤500ml----±1g
Filling machine for volume ≥500ml----±2g
Power supply AC380V,50Hz; AC220V,50Hz (customized)
Air consumption 0.55-0.65 Mpa clean and stable compressed ai
Diameter of bottle mouth Customized



Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle 0Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle 1Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle 2


Configuration List:


Name Brand
PLC Mitsuibish
Air switch Meanwell
AC contactor Schneide
Time relay Omron
Inverter Corkan
Electromagnetic valve Airtac
Cylinder Airtac
Sensor Keyence
Touch screen Siemens


Our factory

Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle 3


Shipping



Automatic Stainless Steel Filling Capping Machine For Olive Edible Oil Glass Bottle 4



RFQ
Q1: Are you a trading company or a manufacturer?

A: We are a manufacturer, we supply the factory price with good quality, welcome to visit.



Q2: What's your guarantee or the warranty of the quality if we buy your machines?

A: We offer you the high quality machines with one year guarantee and supply long life technical support.



Q3: When can I get my machines after I paid?

A: The delivery time is based on the exact machine you confirmed.



Q4: How can I install my machines when they arrive?

A: We will send our engineers to your factory to install the machines and train your staffs how to operate

the machines.



Q5: How about the spare parts?

A: After we deal with all the things, we will offer you a spare parts list for you refer.
