Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can

China SUZHOU LABELONG PACKAGING MACHINERY CO.,LTD certification
China SUZHOU LABELONG PACKAGING MACHINERY CO.,LTD certification
I'm Online Chat Now

Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can

Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can
Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can

Large Image :  Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can

Product Details:

Place of Origin: China
Brand Name: Labelong
Certification: CE
Model Number: L-SP8

Payment & Shipping Terms:

Minimum Order Quantity: One set
Price: USD9000-12000
Packaging Details: Wooden case
Delivery Time: 20-40 days
Payment Terms: T/T OR L/C
Supply Ability: 50-100SET/YEAR
Detailed Product Description
Product Name: Shrink Packing Machine Degree: 260 Degree
Speed: 8pcs/Min Application: Food, Beverage, Medicine
Capacity: 8-9pcs Per Minutes Max. Product Size: 270*650*350mm
Suitable Plastic Film Thickness: 0.03-0.15mm Condition: New
Grade: Automatic Control: PLC Control
Highlight:

Automatic L Type Shrink Packing Machine

,

PET Can Shrink Packing Machine

,

30kw Shrink Film Packaging Machine



Automatic L type beverage Shrink film Packing Machine for PET/Glass bottle/can



Shrink film package series

Shrink Wrapping machine

Packing Machine

Automatic shrink film packaging machine is a continuous film roll, according to the required length of the film cut to the vacuum suction of the plastic film transported to the bottom of a group of containers, containers continue to move forward while the plastic film wrapped by the lever Container and superimposes the end of the film onto the plastic film over the container, followed by the plastic film-coated container being fed into the heating channel and finally forming the automated packaging technology for the film wrapping product.



Including container feeding, container grouping arrangement, film unwinding device, film cutting system, film conveying, shrink film winding and shrinking furnace.



Can be packaged in different containers, such as: plastic bottles, glass bottles, cans, jars or a number of small packages.

Automatic shrink film packaging machine continuous linear.



Capacity 8-9pcs per minutes
Max. product size 270*650*350mm
Max. packing size 600*650*450mm (L*W*H)
Suitable plastic film thickness 0.03-0.15mm
Heating temperature 260 degree adjustable
Working pressure 0.6-0.8Mpa
Input Power 3PH 380V 50HZ
Motor power 30kw
Machine size (L)12000×(W)1100×(H)2100
Machine weight 2400kg



Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can 0Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can 1Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can 2Automatic L Type Beverage Shrink Packing Machine For PET / Glass Bottle / Can 3
